Yamaha Pro MG12 Yem Audio Mixer

12-Channel Mixing Console: Max. 6 Mic / 12 Line Inputs (4 mono + 4 stereo) / 2 GROUP Buses + 1 Stereo Bus / 2 AUX

  • 12-Channel Mixing Console
  • Max. 6 Mic / 12 Line Inputs (4 mono + 4 stereo)
  • 2 GROUP Buses + 1 Stereo Bus
  • 2 AUX
  • “D-PRE” mic preamps with an inverted Darlington circuit
  • 1-Knob compressors
  • PAD switch on mono inputs
  • +48V phantom power
  • XLR balanced outputs
  • Internal universal power supply for world-wide use
  • Optional Rack Mount Kit RK-MG12 Available
  • Metal chassis
  • 308 mm x 118 mm x 422 mm (12.1″ x4.6″ x16.6″)
  • Net Weight: 4.0 kg (8.8 lbs.)


The Yamaha MG12XU Mixing Console shall be a versatile 12-channel mixer that is suitable for a wide range of users and applications.

The MG12XU shall have 12 line inputs (4 mono, 4 stereo) and 6 microphone inputs with 48-volt phantom power and a high-pass filter for each channel. Two stereo outputs, one monitor output, two auxiliary (effects) sends, two group sends, and one headphone output shall be provided.

One stereo bus, two group buses, and two auxiliary (effects) buses shall be provided. The mixing console’s microphone preamplifiers shall discrete class-A “D-PRE” types for high sound quality. Yamaha’s 1-knob compressors with LED indicators shall be included for easy
compression control.

A digital effects processor with 24 high-quality “SPX” effects shall be included to allow creative sound processing. The mixing console shall be equipped with a 24-bit/192-kHz 2-in/2-out USB digital audio interface, and shall be supplied with an access code that will allow Cubase AI music production software to be downloaded from the Steinberg website. Steinberg’s Cubasis LE multi-touch sequencer
for the iPad and Yamaha’s MG Rec&Play recording application for the iPad and iPhone shall be available for download from the App Store at no charge.

The mixing console shall be robust and built into an impact-resistant powder-coated metal chassis. The mixing console shall have an internal universal power supply that is capable of powering the unit stably from AC mains voltages around the world. Dimensions shall be 308 (W)
x 422 (D) x 118 (H) mm (9.6″ x 11.6″ x 2.8″). Weight shall be 4.2kg (9.3lbs)
